Toft Audio Designs EC-1 EQ/Preamp


Download

Click here to download the EC-1 Manual


• High quality mic pre-amp with selectable 48 volt phantom power, phase reverse, front panel instrument input and selectable line input.

• Extremely musical four band sweep eq. section.

• Equalizer can be switched pre/post compressor.

• Balanced xlr input for mic, balanced xlr and jack for line input and line output.

• Extremely competitive price.




• Classic F.E.T compressor with variable attack, release and ratio. V.U. metering shows gain reduction and output level.

• Compact 1U rack mounting unit effectively provides a complete recording channel in one conveniently sized rack unit.

• 1/4” thick anodized aluminum sculptured front panel and solid construction.



Technical Specifications

Microphone Impedance:
>1.2K- ohm balanced
Line Impedance:
>15K ohm electronically balanced
Instrument Impedance:
>100K ohm unbalanced
Microphone Gain:
60dB
Line Gain:
-16 to +30dB
Instrument Gain:
36dB
Output Impedances:
XLR: <100 ohm electronically balanced Jack: <100 ohm unbalanced
Microphone Input Noise:
Microphone: <-128dBu ref 150 ohm (20Hz-20kHz)
Line Input Noise:
Line: <-75dBu (Eq. In, 20Hz-20kHz) <-70dBu (Compressor In, 20Hz-20kHz)
Maximum Mic Levels:
Mic Input: <+24dBu at all frequencies (Compressor out)<+15dBu at all frequencies (Compressor in
Maximum Line Levels:
Line Input: <+24dBu at all frequencies (Compressor out)<+15dBu at all frequencies (Compressor in)
Maximum Instrument Levels:
Instrument Input: <+24dBu at all frequencies (Compressor out) <+15dBu at all frequencies (Compressor in)

 $699.99 (ready to ship)
