Shelby Lynne tracking with the VIN-JET







Cascade Microphones Ribbon Microphone V57



New Live/Stage/Studio FAT HEAD II

Special Introductory Offer for RecordingReview Subscribers only

$199.00



 Free with your order

Custom 20 ft. Mogami NEGLEX 2534 Quad Microphone Cable with Neutrik Gold Contact XLR Connectors.

Free with your order



Quote: Michael Britt (lead guitar, background vocals) Lonestar

I was using one of the other brand name ribbons on my touring rig, I was told to try the new Cascade 5 micron, "it is absolutely stunning" I'll never go back to the other one.



Preview Gussi Miller using one FAT HEAD II LIVE/STAGE/STUDIO as a room mic (the LIVE/STAGE is the only mic used)  +

CASCADE FAT HEAD II - Ribbon Microphone

Legendary symmetrical ribbon design is incorporated into the FAT HEAD II

Unlike most ribbon motors designed today with an offset ribbon element the new Cascade FAT HEAD II houses a hand-tuned ribbon element that incorporates the legendary symmetrical ribbon design. This design offers a true figure 8 pattern. The corrugated aluminum membrane itself is positioned in the center from front to back, thus producing a balanced audio input signal to both sides of the ribbon assembly. This design is very useful when executing a mid-side or Blumlein recording set-up and also great for live stage use.

The Cascade FAT HEAD offers the natural and open sound associated with the finest ribbon microphones. You will find that when recording acoustic guitars, guitar cabinets, vocals, drum over-heads, and countless other types of instruments, the ribbon microphone will produce the warmth that is vital to today's digital recording environment. We firmly believe you will also agree that this microphone will make a great addition to your collection.

We inspect the audio and built quality of each and every Cascade microphone before it leaves our shop, once you try one...you'll be a believer.

Specifications:

  • Type: Ribbon (velocity) Microphone
  • Ribbon type & Dimensions: 99% Pure aluminum, 5 micron, 1 3/4" (L) X 3/16" (W)
  • Polar pattern: Figure 8 Symmetrical
  • Sensitivity: -56 db +/- 2 dB (0 dB=1V/Pa)
  • Frequency response: 30 to -18,000 Hz (+/- 3dB)
  • Output Impedance: <=200 Ohms
  • Recommended load impedance: >1000 Ohms
  • Max.SPL (1% THD @1000 Hz): 165 dB
  • Connector: 3-Pin male XLR
  • Size: Diameter: 3” (O.D. grill), overall length 7 3/4"”, 1 3/4" (O.D. body)

Includes:

  • FAT HEAD II Ribbon Microphone

  • Premium suspension shockmount

  • Quality wood box with heavy-duty latch and hinges

  • Upgrade aluminum case

  • Micro-fiber cleaning cloth

  • Micro-fiber storage pouch


Choose body/grill color
Choose Color
FAT HEAD II Live/Stage/Studio $199.00 Now Shipping

Includes Free 20' Mogami Cable
