C77 Short Ribbon Microphone

Visually, the C77 is reminiscent of classic ribbon microphones of the past but with a twist. Here at Cascade we have been listening to customer feedback and have designed our premium series of microphones to meet the wants, needs, and desires of all studio users while still keeping our products at an affordable price.

The C77 comes fitted with a Lundahl LL2913 transformer mounted on a custom PCB board, along with Evidence Audio solid-core copper wire and a Chicago Switchcraft XLR connector. The C77 features a symmetrical ribbon design and is assembled at the Cascade Lab located in Olympia, WA.

We feel Cascade Microphones has raised the bar with the C77 by combining premium components with a superior finish at an affordable price point that is attractive to both the seasoned studio veteran as well as the home recording enthusiast.

C77 Short Ribbon Microphone with

2913 Lundahl Transformer........ $499.99

Jim Messina and Michael Chiriac

Specifications

More Information

Alternate Images

Accessories

Specifications:

Type: Ribbon (velocity) Microphone
Ribbon type & Dimensions: 99% Pure aluminum, 2.5 micron, 1 3/4" (L) X 3/16" (W)
Polar pattern: Figure 8 Symmetrical design
Sensitivity: -56 db +/- 2 dB (0 dB=1V/Pa)
Frequency response: See PDF below
Output Impedance: <=200 Ohms
Recommended load impedance: >1000 Ohms
Max.SPL (1% THD @1000 Hz): 135 dB
Connector: 3-Pin male XLR
Size: Diameter: overall ngth 7 7/8", 2 9/16" (O.D. body)

FItted With:

Lundahl LL-2913 Transformer

We mount a Lundahl LL-2913 to a custom fitted circuit board. This reduces the wiring needed as well as giving you the full advantage of the Lundhal transformer.

Includes:
